About this item

• Anode and cathode are electrodes in the electrolysis process, and the choice of their materials is very important for the efficiency and energy consumption of electrolysis. Hydrogen gas production: 600ml/min (Difference range ±3%) Oxygen gas production: 300ml/min (Difference range ±3%) Water consumption: less than 36ml/h (hydrogen outlet and oxygen outlet water are returned to the tank)
• Water consumption: less than 36ml/h (hydrogen outlet and oxygen outlet water are returned to the tank) Cyclic Mode: Gravitational cycle (the vertical distance between the water outlet of the tank and the water inlet of the electrolyzer should be greater than or equal to 15 cm) Electrolytic method: pure water electrolysis (without adding lye, safe and reliable, easy to maintain)
• Working pressure: 0.1~1.3Mpa Water source requirement (TDS) : Can use purified water, secondary distilled water, or deionized water <5ppm Power Supply: Rated current: 20A (constant current power supply) Output voltage: 5V Size: 99x113x35.5MM (excluding terminal panel and connectors) Net weight :1.1~1.3KG"
• SPE PEM latest technology: Using the latest SPE(solid-state polyelectrolysis technology)+ PEM(proton exchange membrane) two-cell electrolyzer. Stronger pressure resistance, higher hydrogen production capacity, does not produce residual chlorine, ozone and other harmful gases.
