【@ :: 】HDMI Extender supports 4K@60Hz up to 40m/130ft, 1080P@60Hz up to 70m/ 230ft over Cat5e/6a/7 cable. Audio Supports Dolby Atmos, DTS:X,Dolby TrueHD,DTS-HD Master, LPCM 2.1/ 5.1/ 7.1CH, provides great picture and fantastic audio.
【 】 Bi-directional PoE, IR and RS232; Automatic EDID management; High compliance hdmi extender with HDCP 2.2/1.4 HDMI1.4 and HDR ( :: ) Ultra-slim with Fix Mounting Ear.
【 】Perfectly work with PC,PS5, XBOX, DVD Player, Apple TV, Satellite Box, Cable Box and most sources; Ideal for Digital Signage, Home Theater, Boardrooms, Workshop, Seminar, Classrooms, Conference, Gaming, Video Production.
【 】HDBaseT Extender certificated by FCC, CE. Preventing thunder strikes, built-in Surge/ Lightning Protection, Superior ESD Protection. One transmitter supports one receiver only. Mounting ear for easy installation. ***New Arrival: HDMI2.0 Fiber Extender ASIN: 【B073QLRJDR】.
【Important Note】This HDMI Extender Does NOT support ARC. order [--] for ARC Extender. Picture flick or signal cut out is caused by bandwidth exceeding, please get the [-] If You wish to enjoy full HDMI 2.0 with latest color standard, .3-Year-Warranty for business customers and Free Lifetime Technical Support (AV Access).
|
| HDEX40-L | 4KEX70-L | 4KEX70-H2 | 4KEX70-ARC-H2 | 4KEX70-eARC | 4KEX100-H2 |
| Supported Resolution | 1080@60Hz | 4K@60Hz 4:2:0 | 4K@60Hz | 4K@60Hz | 4K@60Hz | 4K@60Hz |
| Transmission Range | 164ft (50m) | 230ft (70m) | 230ft (70m) | 230ft (70m) | 230ft (70m) | 330ft (100m) |
| IR Control | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ |
| HDMI Version | 1.3 | 1.4 | 2.0 | 2.0 | 2.0 | 2.0 |
| HDCP Version | 1.4 | 2.2 | 2.2 | 2.2 | 2.3 | 2.2 |
| POE | Uni-Direction | Bi-Direction | Bi-Direction | Bi-Direction | Uni-Direction | Bi-Direction |
| RS232 | × | ✓ | ✓ | ✓ | ✓ | ✓ |
| ARC/eARC | × | × | × | ARC | eARC | × |
