Square D QO3100BNF Enclosure Qo Circuit Breaker 240V 100A Nema 1Flush - Shop Hardware Tools Online Store

QO load centers offer premium features by allowing QO breakers, ground arc fault interrupters arc fault interrupters and surge arresters to be installed inside QO load centers enable the use of a full complement of accessories. Systems can be single or three phase and have indoor and outdoor versions. Indoor enclosures are designed to rotate 180 degrees to accommodate top or bottom service entrance feed which saves expensive service cable. QO load centers feature plated copper bus, providing superior performance and durability. This enclosure is for a three phase 100 A at 240 VAC QO breaker. This QO breaker in this enclosure has a 22 kA breaking capacity. This enclosure has an insulated groundable neutral. This system provides 3 spaces in a NEMA 1 enclosure. This enclosure has a flush cover. The lugs will accept 14 AWG to 1 AWG copper wire and 12 AWG to 1 AWG aluminum wire. The enclosure is 13.11 inches tall, 5.87 inches wide and 3.31 inches deep. The load center enclosure is UL listed.
