Built-in ESS SABRE HIFI DAC MX5 built-in ESS SABRE HIFI DAC, with XMOS XU208 & Qual-comm QCC3031, bring excellent performance to the MX5 with UsB, optical fiber, coaxial, Bluetooth input. This allows the MX5 to easily access a variety of audio sources including computers, set-top boxes, CD players, mobile phones, tablets, etc.In addition to supporting various digital inputs, MX5 also supports fully balanced TRS and single-ended RCA analog inputs. Greatly expand the scope of application
Auto On/Off - MX5 supports Auto On/Off function in all inputs. When a valid signal is detected, it will be turned on immediately. When the valid signal is lost, it will automatically shut down (Turn to standby mode) within a specific time.For analog signals of different strengths, MX5 provides three options of sensitivity to ensure that the signal can be accurately detected.Note: The digital signal detection is turned on by default.
Merus Class D amplifier - With the help of Infineon Merus Class D amplifier, MX5 can output 70W x2 under 4 ohm load 10% distortion, 55W x2 under 4 ohm load 1% distortion. Under 8 ohm load, 10% distortion can output 42W x2, and 1 % distortion can output 35W x2, which can meet daily use
NFCA Headphone Amplifier - The MX5 has the NFCA circuit optimized for this unit, giving the ultra low noise and distortion. It pairs with high sensitivity IEMs and power hungry high impedance headphones nicely. The built-in headphone amp allows you to enjoy music by yourself without dis- turbing others. Built-in EQ function,now you can adjust treble and bass MX5 supports users to adjust the treble and bass. The treble and bass provide adjustable ranges from -10dB to +10dB respectively.
2 step gain settings for both - In order to adapt to input signals with different strengths, MX5 provides two step gain settings for both power amplifier and headphone amplifier. The gain can be set on the remote control.MX5 provides two custom setting memories，C1 and C2.Long press can memorize the current input selection，output selection，volume setting，bass setting，treble setting，and gain setting，And short press to call out in subsequent applications。It greatly facilitates your use
USB IN
PCM: 44.1kHz-384kHz/16bit - 32bit
DSD(Native):DSD64 - DSD256
DSD(Dop):DSD64 - DSD128
OPT/COAX IN
PCM:44.1kHz-192kHz/16bit - 24bit
BT IN
PCM:AAC/SBC/APTX/APTX LL/APTX HD
